This extension provides a complete set of ViewHelpers that allow you to use FPDF (a PHP PDF library) with Fluid. All you need to be able to use the viewhelpers in your own extension is to define the fpdf namespace. You can then use predefined PDF files using the integrated plugin. The plugin gives you access to all available PDFs. You can also set a customized PDF design as a background image, create PDF lists of content, and access font subsets so that RTE text can be output in bold, italic, underlined, as a list, etc.

Key Features

All FPDF library functions available as ViewHelpers
PDFS can be saved as a file or output directly as download
Customised PDF design can be set as background image
PDF content listings/indexes/table-of-content can be created
Font subsetting available (text from RTE is parsed written in PDF, possible tags: h1, h2, h3, h4, h5, b, u, i, a, p, br, pagebreak, strike, strong, small, em, ul, ol, li, dl, dt, dd)
Bookmarks inlc. linking can be generated
Barcode generator
Free-of-charge with an open source license
 € 0,00 ex. VAT


TYPO3 7.6TYPO3 6.2StableTYPO3 8.7OpenSourceTYPO3 9.5PHP 7.1PHP 7.2PHP 7.3PHP 7.4TYPO3 10.4FreePHP 8.0TYPO3 11.5PHP 8.1PHP 8.2TYPO3 12.4

Change Log

Fluid-FPDF for TYPO3 Change-Log

2023-12-10 Release of version 2.6.0

  • [FEATURE] Add view helper for rotating text

2023-12-05 Release of version 2.5.2

  • [BUGFIX] WriteHtmlTrait::PutLink() calls Write() with fix line height
  • [TASK] Optimize version conditions in PHP code

2023-11-13 Release of version 2.5.1

  • [BUGFIX] Fix bullet list and paragraph line breaks in HTML printing

2023-11-10 Release of version 2.5.0

  • [FEATURE] Introduce dl, dt, dd tags in HTML for definition lists for HtmlMultiCell
  • [BUGFIX] Improve HTML tag documentation in features

2023-11-02 Release of version 2.4.6

  • [BUGFIX] Remove red debugging table border

2023-11-01 Release of version 2.4.5

  • [TASK] Clean up documentation

2023-10-27 Release of version 2.4.4

  • [BUGFIX] Fix access on non defined ctype index in backend preview

2023-09-22 Release of version 2.4.3

  • [TASK] Refactor and optimize HtmlMultiCellViewHelper
  • [TASK] Introduce tag in HTML for triggering a PDF page break
  • [TASK] Update and extend documentation

2023-09-20 Release of version 2.4.2

  • [TASK] Introduce listMarginBottom listIndentMargin attribute for HtmlMultiCellViewHelper

2023-09-13 Release of version 2.4.1

  • [BUGFIX] Fix SetFontViewHelper for nullable style argument

2023-09-04 Release of version 2.4.0

  • [TASK] Migrate to TYPO3 12 and remove support for TYPO3 10

2023-02-23 Release of version 2.3.7

  • [TASK] Generated documentation for TypoScript constants
  • [TASK] Normalize and migrate configuration files
  • [BUGFIX] Fix undefined array index in CellViewHelper for PHP 8+
  • [BUGFIX] Fix H tags and gaps after UL tags

2022-11-14 Release of version 2.3.6

  • [BUGFIX] Suppress warning in WriteHtmlTrait
  • [BUGFIX] Fix type issue in Barcode trait

2022-07-28 Release of version 2.3.5

  • [BUGFIX] Suppress warning on file_exists in Image ViewHelper

2022-05-27 Release of version 2.3.4

  • [BUGFIX] Fix image paths for TYPO3 11
  • [BUGFIX] Fix view helper namespaces

2022-05-12 Release of version 2.3.3

  • [TASK] Add replace and explode ViewHelper

2022-04-23 Release of version 2.3.2

  • [TASK] Insert index space check
  • [TASK] Move extension icon into public folder
  • [BUGFIX] Fix casting issue in index creation

2022-04-16 Release of version 2.3.1

  • [TASK] Add condition for ADD_PAGE in HTML output for triggering new pages
  • [BUGFIX] Fix spaces in beginning of a line after a line break

2022-02-07 Release of version 2.3.0

  • [TASK] Optimize code style
  • [TASK] Clean up Documentation files
  • [TASK] Clean up PHP sources and dividing by traits
  • [BUGFIX] Fix documentation configuration
  • [TASK] Update FPDF library to version 1.84
  • [TASK] Migration for TYPO3 11.5 - remove support for TYPO3 9.5
  • [TASK] Add documentations configuration

2022-05-12 Release of version 2.2.2

  • [BUGFIX] Fix explode ViewHelper limit

2022-05-12 Release of version 2.2.1

  • [BUGFIX] Fix spaces in beginning of a line after a line break
  • [TASK] Add replace and explode ViewHelper

2021-06-10 Release of version 2.2.0

  • [FEATURE] Add barcode ViewHelper

2021-01-13 ## Release of version 2.1.5

  • [BUGFIX] Fix deprecation notices in old PHP array usage

2020-11-30 Release of version 2.1.4

  • [TASK] Remove quotation mark from description

2020-11-19 Release of version 2.1.3

  • [TASK] Extend extra tags in composer.json

2020-06-19 Release of version 2.1.2

  • [TASK] Add extra tags in composer.json
  • [TASK] Reformat ChangeLog.md

2020-06-19 Release of version 2.1.1

  • [BUGFIX] Remove use statements from ext_tables and ext_localconf

2020-04-06 Release of version 2.1.0

  • [BUGFIX] Fix Flexform registration and render types
  • [TASK] Source code optimizations
  • [BUGFIX] Fix usage of $EXTKEY for TYPO3 10.4
  • [TASK] Migration for TYPO3 10.4
  • [TASK] FPDF library upgrade

2020-04-02 Release of version 2.0.5

  • [BUGFIX] Fix output to local file

2020-03-02 Release of version 2.0.4

  • [BUGFIX] Fix GetStringWidth ViewHelper parameter definition

2019-10-13 Release of version 2.0.3

  • [TASK] Add Gitlab-CI configuration.
  • [TASK] Change image urls in the documentation.

2019-02-27 Release of version 2.0.2

  • [BUGFIX] Removing DEV identifier.

2019-01-28 Release of version 2.0.1

  • [BUGFIX] Fixing argument definition in SetFontSize ViewHelper.

2019-01-28 Release of version 2.0.0

  • [TASK] Migration for TYPO3 9.5.
  • [FEATURE] Adding paragraphMarginBottom attribute in HtmlMultiCell-ViewHelper.
  • [BUGFIX] Removing double UTF8 encoding in Cell-ViewHelper.
  • [TASK] Optimizing spaces between ol/ul li in HtmlMultiCell.

2018-08-23 Release of version 1.13.0

  • [FEATURE] Adding HtmlMultiCell ViewHelper, which is able to handle the following HTML tags: b, u, i, a, p, br, strike, strong, small, em, ul, ol and li
  • [BUGFIX] Fixing conposer.json.
  • [FEATURE] Adding UTF8 Encode ViewHelper.
  • [BUGFIX] Fixing encoding issue in Cell ViewHelper.

2018-06-04 Release of version 1.12.0

  • [FEATURE] Adding possibility to pass variables into Footer-Template (see Readme.md).

2018-02-22 Release of version 1.11.1

  • [BUGFIX] Fixing image path issue by using config.absRefPrefix = /.

2018-02-02 Release of version 1.11.0

  • [BUGFIX] Fixing image path issue by using config.absRefPrefix = /.
  • [FEATURE] Adding IsValidImage-ViewHelper for checking a valid image type. It check if an image is vector based and if the image owns a supported file extensions.
  • [BUGFIX] Fixing UseTemplate-ViewHelper, which import the first page twice.
  • [TASK] Updating the FPDI library to version 2.0.0.

2018-01-13 Release of version 1.10.1

  • [BUGFIX] Fixing AddFont-ViewHelper.

2018-01-11 Release of version 1.10.0

  • [FEATURE] Adding support for EPS and AI image files.
  • [FEATURE] Adding custom sizes for pages. Instead of using A4, just use 213x321 in mm.

2017-11-23 Release of version 1.9.0

  • [TASK] Get template container variable optimization
  • [TASK] Adding new demo in documentation
  • [FEATURE] Adding ViewHelper for GetImageHeightFromWidth and GetImageWidthFromHeight

2017-11-19 Release of version 1.8.0

  • [FEATURE] Adding UTF8-Decode ViewHelper

2017-10-24 Release of version 1.7.0

  • [BUGFIX] Fixing image ViewHelper. By using config.absRefPrefix the image path is broken.
  • [FEATURE] Adding Footer feature
  • [BUGFIX] Fixing ViewHelper attribute inline line breaks

2017-09-27 Release of version 1.6.0

  • [FEATURE] Adding GetImageOrientation ViewHelper for identifying, if an image is portrait, landscape or squared.
  • [FEATURE] Adding SetFontSpacing ViewHelper for setting letter spacing.
  • [BUGFIX] Fixing pageno ViewHelper
  • [FEATURE] Adding GetIndexOrientation ViewHelper for writing a customized index.

2017-09-25 Release of version 1.5.0

  • [BUGFIX] Fixing page module content preview
  • [FEATURE] Adding Bookmarks feature (see: http://fpdf.org/en/script/script1.php).
  • [FEATURE] Adding Index feature (see: http://fpdf.org/en/script/script13.php).
  • [FEATURE] Adding GoToPage-ViewHelper for getting to previous pages (see: FpdfTutorialIntroIndex.html example).
  • [BUGFIX] Fixing encoding of windows quotes
  • [BUGFIX] Fixing style (N === '') in SetFont PDF-ViewHelper

2017-07-09 Release of version 1.4.2

  • [BUGFIX] Support for destination S in PDF-ViewHelper
  • [BUGFIX] Fixing exit in PDF-ViewHelper

2017-06-15 Release of version 1.4.1

  • [TASK] Fixing version numbers

2017-06-14 Release of version 1.4.0

  • [TASK] Migration to TYPO3 8.6

2017-04-11 Release of version 1.3.0

  • [FEATURE] Adding Debug/FontDump-ViewHelper for dumping all characters with ASCII-No.
  • [FEATURE] Adding Debug/StringCharacterDump-ViewHelper for dumping all characters from a string (with ASCII-No.)
  • [FEATURE] PDF-ViewHelper now got a characterMap attributes, which allows you to map characters to other ASCII-No. within the PDF-Font.
  • [TASK] SetFont-ViewHelper: Attribute style: Default value is now 'N'
  • [TASK] UseTemplate-ViewHelper: Attribute pageNo: Default value is now '0'
  • [TASK] Documentation
  • [BUGFIX] Fixing GetStringWidth ViewHelper

2015-09-02 Release of version 1.2.1

  • [BUGFIX] Fixing conversion of the euro symbol

2015-09-02 Release of version 1.2.0

  • [TASK] PHP 7 compatibility
  • [FEATURE] Adding GetPageWidth- and GetPageHeight-ViewHelper
  • [TASK] Upgrade to FPDF 1.8.1
  • [FEATURE] Adding hex color parameter for SetDrawColor-, SetFillColor- and SetTextColor-ViewHelper

2015-05-19 Release of version 1.1.0

  • [FEATURE] Adding FPDI feature, merge existing PDF-Pages to PDF
TYPO3 Fluid-FPDF Extension


Use Fluid-ViewHelper for dynamic PDF generation.

Free available

  • Issue-Tracker access
  • Product documentation
  • No time limit

Price 0,00 € excl. VAT
