Guided tours for TYPO3

The guided tour extension (EXT:guide) for TYPO3 provides you the ability for creating guided tours through the TYPO3 backend. Thesetours should give editors an introduction of different areas and features, so that he easily finds out who to use TYPO3.

The different guided tours are configured by page TypoScript (tsconfig). Translation values are provided as usually byXLIFF files.

Developers of third party extensions have the ability to provide own guided tours for their backend modules.

Backend module

The guided tour extension comes with an own backend module, which you will find in the help menu in the topbar ofthe TYPO3 backend. It will list you all (for your current user accessible) guided tours. You're able to start each touror resume tours which you have started once. Additionally you're able to reactivate tours, that you had marked as Don'tshow again.

Let's take a look at how the guided tours work in detail and how you're able to modify existing tours orcreate your own.

Definition of a guided tour

All tours must defined in the page TypoScript node mod.guide.tours. A definition of a tour for the View module wouldbe like this:

mod.guide.tours.ViewModule {
    # here comes your guided tour configuration
}

The main node of a tour is the internal name as well.This name should be a simple upper-camel-cased string.

Within this tour node we need some required nodes, which can be defined like this:

mod.guide.tours.ViewModule {
    # The title of the tour. This title will be displayed in the backend module.
    # Enter simply some text or use a LLL identifier.
    title = LLL:EXT:guide/Resources/Private/Language/BootstrapTourViewModule.xlf:tx_guide_tour.title
    # Description of the tour. This description will be displayed in the backend module.
    # Enter simply some text or use a LLL identifier.
    description = LLL:EXT:guide/Resources/Private/Language/BootstrapTourViewModule.xlf:tx_guide_tour.description
    # Internal name of the module.
    # This is the same identifier like the module key (M parameter in backend links)
    # The moduleName core is used for tours, which are execute in top frame.
    # Examples:
    # - Page module: web_layout (a tour which is executed in page module)
    # - View module: web_ViewpageView (a tour which is executed in view module)
    moduleName = core
    # Icon identifier for the icon in backend module.
    # The icon identifier has to be registered in the icon registry.
    iconIdentifier = module-guide-tour-core
    # In the steps node you have insert a node for each popover you want to display.
    steps {
        # The key of the steps should be numeric and defines the order of displaying the popover
        10 {
            # ...
        }
        20 {
            # ...
        }
        # A step key can also be defined by a key name.
        # This can be useful, if you like to jump to this step without knowing his step number.
        step-key-by-key-name {
            # ...
        }
    }
    # Steps configuration can have a path to a YAML file with the step configuration. This field is optional.
    # By setting your step configuration with this path, you're able to provide conditional steps depending on TYPO3
    # Major version. Additionally the steps are dynanical reloaded and the Page-TypoScript (tsconfig) remains small.
    stepsConfiguration = EXT:guide/Configuration/Tours/

Step configuration

Each step node can be configured like this:

# The selector is passed to jQuery for selecting the HTML-Element, on which the popover should be placed.
# This selector must be unique in DOM. A selector can also be a unique data attribute/value.
# Examples:
# selector = #some-id
# selector = .some-unique-class
# selector = .some-multiple-used-class:first
# selector = select[name=\'WebFuncJumpMenu\']:first
# selector = [data-identifier='apps-toolbar-menu-shortcut']
selector = .typo3-aboutmodules-inner-docbody
# This is the title of the popover.
# Enter simply some text or a LLL identifier like:
# title = LLL:EXT:guide/Resources/Private/Language/BootstrapTourPageModule.xlf:tx_guide_tour.0.title
title = Welcome to TYPO3 backend
# This is the content of the popover.
# Enter simply some text or a LLL identifier like:
# title = LLL:EXT:guide/Resources/Private/Language/BootstrapTourPageModule.xlf:tx_guide_tour.0.content
# You're also be able to use HTML tags like i, u, b, br or p. Additionally there is an img tag for displaying icons,
# which must have a data-icon-identifier attribute with the icon identifier. Such an icon usage could look like:
# <img data-icon-identifier="module-web_layout"/>
# There is a <action> tag, which allows you the define actions for the user, which will be designed noticable.
# All other tags are disallowed.
content (
 This tour will show you the first steps within TYPO3.<br />
 You're starting here in the <img data-icon-identifier="module-help_AboutAboutmodules"/> <i>about</i> module,
 which shows you your available modules.
 This modules are related on the giving user authorisation.<br />
 <br />
 Click on <i>Next</i> for an introduction of the topbar of TYPO3.<br />
 <br />
 <i>(You can restart each tour by the guided tours module.)</i>
)
# Defines the position of the popover.
# Possible values are: top, bottom, left, right, auto
placement = top
# Disables the arrow on popover.
# The arrow is displayed by default.
showArrow = false
# Enables a backdrop.
# This feature is currently in incubation
backdrop = false
# Set a padding for the backdrop
backdropPadding = 0
#
# The following nodes can be used for executing some actions during the tour.
#
# The next node contains actions, which are triggered by clicking the next button
next {
    # More information below...
}
# The show node contains actions, which are triggered by starting to show this step
show {
    # More information below...
}
# The shown node contains actions, which are triggered by finishing to show this step
shown {
    # More information below...
}
# The hide node contains actions, which are triggered by hiding a step
hide {
    # More information below...
}

The next node

The next node contains actions, which are triggered by clicking the next button. So you're able to trigger another tourin the last popover, just by clicking the next button.

# By clicking on next, the tour Topbar is triggered
tour = Topbar
# The number/id of the step, which should be displayed of the called tour
step = 0
# StepByKey resolves the step number by the key.
# Internally it runs through the required tour and counts the steps till the defined stepByKey is found. Finally it set
# the counted value into the step-attribute - this means, if you are using stepByKey the step-attribute isn't required.
stepByKey = step-key-by-key-name

The show node

The show node contains actions, which are triggered by starting to show this step. This means in detail, the action isexecuted before the tour starts the displaying process.With help of this node you're able to execute actions, like adding or removing a CSS class to an element or open selectboxes in order to show specific values.

# Renames the label of the next button of the popover.
# This is useful, when you're starting another tour by clicking the next button.
renameNextButton = Start next tour
# Add a class on an element. This is useful, when you want to highlight a special element.
addClass {
    # jQuery selector for identifying elements, which should get the class.
    selector = #typo3-cms-backend-backend-toolbaritems-usertoolbaritem
    # Class to be added
    # Attention: Because of an focus issue, opening a dropdown
    # by adding the class open is only working with event shown.
    class = open
}
# Removes a class from an element.
removeClass {
    # jQuery selector for identifying elements, which should lose the class
    selector = #typo3-cms-backend-backend-toolbaritems-usertoolbaritem
    # Class to be remove
    class = open
}
# Opens a select box by jQuery selector
openSelectBox {
    selector = select[name=\'WebFuncJumpMenu\']:first
}

The shown node

The shown node contains actions, which are triggered by finishing to show this step. This means in detail, the action isexecuted after the popover is completely visible. The available actions in this nodes are equal to the show node.

The hide node

The hide node contains actions, which are triggered by hiding a step. The available actions in this nodes are equal tothe show node.

Modify existing tours or create your own

Since guided tours are defined by simple page TypoScript (tsconfig), the modifying of an existing tour or creating a newtour can be done in different ways.

  • If you want to provide a tour with your own extension or extension-theme, just create a page TypoScript file in your favorite location,for example in EXT:your_ext/Configuration/PageTS/GuidedTour.pagets. This file needs to be included by yourext_localconf.php:

    <?php
    if (!defined('TYPO3_MODE')) {
        die('Access denied.');
    }
    if (TYPO3_MODE === 'BE') {
        // Add page typoscript tours
        \TYPO3\CMS\Core\Utility\ExtensionManagementUtility::addPageTSConfig(
            '<INCLUDE_TYPOSCRIPT: source="FILE:EXT:' . $_EXTKEY . '/Configuration/PageTS/GuidedTour.pagets">'
        );
    }

    These configuration file contains all your modifications of a existing tour or a definition of a new guided tour.

  • If you don't have an own extension, you are able to modify a tour by user TypoScript. You can do this by adding thechanges directly within the respective user or, if you want to change tours for multiple users, within a backenduser group - so you're able to assign the same tours/tour modifications to multiple users.

Modification example

For example, if you want the second popover of the ViewModule tour append on the right instead of the bottom,you would insert a TypoScript like that:

mod.guide.tours.ViewModule {
    steps.20.placement = right
}

In the same way you're able to provide new defined guided tours.

Adding new tours by using PHP

Since version 2.0.0 you're able to define new tours by PHP. The advantage of this is, that you can outsource the stepconfiguration into external yaml-files and the Page-TypoScript isn't so overloaded by processing all the steps again andagain. This definition can be done by a short entry in your ext_localconf.php. This could look like:

\Tx\Guide\Utility\GuideUtility::addTour(
    'TemplateModule',
    'LLL:EXT:guide/Resources/Private/Language/BootstrapTourTemplateModule.xlf:tx_guide_tour.title',
    'LLL:EXT:guide/Resources/Private/Language/BootstrapTourTemplateModule.xlf:tx_guide_tour.description',
    'web_ts',
    'module-web_ts',
    'EXT:guide/Configuration/Tours/'
);

The \Tx\Guide\Utility\GuideUtility::addTour required the following parameters:

  1. The tour identifier equally to the definition by Page-TypoScript.
  2. The title for the tour. This can be a localization identifier too.
  3. The description for the tour. This can be a localization identifier too.
  4. The Module-Key of the tour. This is the same like the m-Parameter of the Module.
  5. The Icon-Identifier for the tour
  6. The base path for your .yaml configuration files. By using this addTour method the .yaml files contain the stepconfiguration of the tour

Note:

When you're defining your tours by this way, you're still able to overwrite your tour in Page-TypoScript (tsconfig)or User-TypoScript. This behaves like descripted above.

Create different steps for different Major versions of TYPO3

By providing your step configuration by using YAML files, you're able to use different steps for different TYPO3versions. Just set the stepsConfiguration setting in your tour configuration on the base folder of your .yaml files,as you've seen in Adding tours by using PHP*. In our tours we set it for example to:

EXT:guide/Configuration/Tours/

Now this base folder needs some sub folder in which the tours for the different TYPO3 versions are stored. Each folderis simply named by the major version number of TYPO3 - for example:

EXT:your_ext
- Configuration
  - Tours
    - TYPO3-7
    - TYPO3-8
    - TYPO3-x

In these folders the guided tour searches for YAML files, which have the same name as your tour identifier.For example, if you're running a TYPO3 LTS 8.7 and you want to define a tour with identifier CreatePage, theguided tours extension would search the steps configuration file in Configuration/Tours/TYPO3-8/CreatePage.yaml
